ALL-IN-ONE DESIGN RLA-6K - Trade Downtown

Description

Smart Power, Easy Install

Built-in dual PV MPPTs, high-efficiency on/off grid inverter, EMS, BMS, and Wi-Fi module with European server.

All-in-one design with auto-alignment battery packs, no cables required, and tool-free installation.

Supports up to 6 battery packs with a maximum capacity of 30.72 kWh, stackable for flexible combinations.

Supports PV ultra-wide voltage range input of 100V-540V, with MPPT up to 7.8 kW.

Fanless cooling system with 0 dB mute design.

IP65-rated, suitable for all home installation environments.

Technical Parameters

RENOPI MODEL	RLA-4B/6K
AC Output
Output Voltage	230V AC
AC Voltage Range	184~276VAC
Output Frequency	50Hz/60Hz; Auto Detect
Frequency Range	45~65Hz
Maximum Frequency	65Hz
UPS Switching Time	<20ms
Rated Output Current	26.09A
Rated Output Power	6000VA
Solar Input
Maximum Solar Output Voltage	550V DC
MPPT Range	100V~540V DC
Maximum Solar Output Power	7.8KW
Rated MPPT Voltage	360V DC
Number of MPPTs	2
Battery Parameters
Battery Type	LiFeP04
Rated Capacity	5120Wh; Max:5120Wh*6
Maximum Charge Voltage	58V
Minimum Discharge Voltage	42.0V
Maximum Continuous Charging Current	100A
Maximum Continuous Discharging Current	100A
Inverter Output
Maximum Output Power	6000VA
Output Voltage	230V AC
Efficiency	97.8%
Rated Output Current	21.7A
Output Frequency	50Hz
THD(%)	<3%
Operating Conditions
Ambient Temperature	-20°C~55℃
IP Rating	IP65
Humidity Range	5%~95% Relative Humidity
Altitude	<3000m
Installation Configurations
Dimensions	600×365 x1521mm
Weight	243Kg
Battery Capacity	5120Whx4
